Electric Heating Boiler

High voltage electrode hot water boiler

Capacity:

2-60MW

Rated Thermal Efficiency:

98%

Pressure:

≤1.0MPa

Applicable fuel:

electric energy

Application industry:

Hot water supply for hotels, sports centers/entertainment venues, heating and hot water supply for tourist attractions

steam-boiler

Product Description

Fangkuai high-voltage electrode hot water boiler adopts a cylinder-type electrode heating structure, three-phase connection, and Y-shaped connection. The main components of the boiler are assembled in the factory, saving a lot of on-site installation time. Small size, light weight, sufficient output, safe and reliable operation, advanced technology: easy installation, simple foundation construction, low investment and convenient maintenance. The boiler has complete automatic control, automatic adjustment and safety protection devices, and is easy to operate. High-voltage insulation between the inner cylinder and the outer cylinder ensures the safety of electricity.

High voltage electrode hot water boiler High voltage electrode hot water boiler

Advantages of high-voltage electric hot water

Cylindrical heating electrode structure, three-phase connection, Y-shaped connection; The main components of the boiler are assembled in the factory, saving a lot of on-site installation time; Small size, light weight, sufficient output, safe and reliable operation, advanced technology; easy installation, simple basic construction, low investment, and easy maintenance;

Advantages of high-voltage electric hot water

The boiler is equipped with complete automatic control, automatic adjustment and safety protection devices, making it easy to operate; high-voltage insulation between the inner and outer cylinders ensures the safety of electricity;

Advantages of high-voltage electric hot water

The patented "vacuum automatic maintenance device" ensures stable and efficient operation of the boiler; The main components of the boiler are assembled in the factory, saving a lot of on-site installation time; Small size, light weight, sufficient output, safe and reliable operation, advanced technology; easy installation, simple basic construction, low investment, and easy maintenance;

Advantages of high-voltage electric hot water

The boiler is equipped with complete automatic control, automatic adjustment and safety protection devices, making it easy to operate; high-voltage insulation between the inner and outer cylinders ensures the safety of electricity;

Learn more

Product Advantages

Fully automatic control

Fully automatic control

Once started, it can run automatically, the water level and temperature are automatically adjusted, and the timer can also be set to turn on and off and start and stop in stages.

The operation interface is intuitive and clear

The operation interface is intuitive and clear

The boiler is equipped with a large-screen full-Chinese LCD display with rich display functions, enabling human-machine dialogue, making it easy to understand, learn, remember, and operate simply and conveniently.

All-round protection

All-round protection

The boiler adopts a fully automatic control mode, which can automatically adjust operation, water level, and water temperature to achieve all-round automatic protection.

Environmentally friendly and pollution-free

Environmentally friendly and pollution-free

Boilers use electricity as energy and do not need to consider the issue of pollution emissions. They are truly environmentally friendly products.

More convenient for users

More convenient for users

The boiler is highly adjustable, and the water temperature can be set arbitrarily between 30-90°C to provide heat for the heating system or provide hot water to users.

Boiler overall high quality

Boiler overall high quality

Valve instruments, controllers, sensors and other important accessories are all from well-known domestic and foreign brands, providing more guarantee for the long-term operation of the boiler.

Small heat dissipation loss

Small heat dissipation loss

The main body is made of high-temperature resistant insulation materials, which can save more heat energy and higher water temperatures. The thermal efficiency of the whole machine is much higher than the standard requirements.

Noiseless operation

Noiseless operation

The operating decibel of the boiler is lower than 62 decibels (normal speech sound), and it can be put into residential areas without disturbing the residents.

Model Parameters

Types Thermal power(MW) Product size L×W×H(mm) Current (A) Working voltage(KV) Operating weight(t)
CLER-2800 2-4 2760×2200×4150 115-230 6.3KV/10KV 7
CLER-5600 6-8 3060×2660×4730 346-461 6.3KV/10KV 10.5
CLER-10500 10-15 3600×2810×4830 577-866 10KV/15KV 13
CLER-14000 16-20 4760×3310×5330 823-1154 10KV/15KV 21
CLER-42000 21-60 3870×3340×6940 1212-3464 10KV/15KV 36
